7-20 Chapter 7
9) For SVC, enter the DTE Address in the Destination DTE Address field.
For PVC, enter the PVC number (which must be configured in the X.25
Profile). Press for a list of configured PVC numbers.
NOTE: PVC Numbers may only be configured provided the
Wan Call Circuit type is Permanent and the X.25
profile for that interface has been defined.
The PVC number must match the Logical Channel Number (LCN)
assigned by the X.25 network service provider at subscription time.
10) In the Destination DTE Address field (if Circuit Type is Switched),
type the address.
This is the X.121 DTE address (up to 15 digits, 0 through 9) assigned to
the specific destination DTE.
11) In the Retry Mode field, accept the mode shown or press to
select another option from the pop-up list.
This parameter specifies the conditions under which a failed connection
is retried. All connection failures are reported to the system console and
to the Call Manager utility (CALLMGR).
The available options are Never Retry, Retry All Failures, Retry Self-
Correcting Failures. The default is Retry Self-Correcting Failures.
12) In the Retry Limit Handling field, press to select the appropriate
option from a pop-up list.
This parameter specifies the action taken when the connection retry
interval exceeds the
Retry Interval Limit (described in Step 12).
For permanent calls, connection retries can either continue indefinitely at
the maximum retry interval (which supports unattended operation) or be
terminated (the connection fails).
On-demand calls can only accept Stop At Limit , which means the
connection fails when the retry interval reaches the limit.
13) In the Retry Interval Limit field, accept the value shown or press
to change it.
