Emulex DCP_link - Manual (Page 48)

Hardware Installation 3-15
RS-232 Standard Cable
TDA
RDA
RTSA
CTSA
DSRA
SG
CDA
TCA
RCA
DTRA
1
2
3
4
5
6
7
8
15
17
20
1
2
3
4
5
6
7
8
15
17
20
DB25
FEMALE
DCP PORT
MODEM OR
OTHER DCE
FG
Figure 3-10 (Not Supplied by Emulex)
