Hardware Configuration 2-17
Switch Port # DTE DCE
SW1 1 1-Closed
2-Open
3-Open
1-Open
2-Closed
3-Closed
2 4-Closed
5-Open
6-Open
4-Open
5-Closed
6-Closed
SW2 3 1-Closed
2-Open
3-Open
1-Open
2-Closed
3-Closed
4 4-Closed
5-Open
6-Open
4-Open
5-Closed
6-Closed
SW3 5 1-Closed
2-Open
3-Open
1-Open
2-Closed
3-Closed
6 4-Closed
5-Open
6-Open
4-Open
5-Closed
6-Closed
SW4 7 1-Closed
2-Open
3-Open
1-Open
2-Closed
3-Closed
8 4-Closed
5-Open
6-Open
4-Open
5-Closed
6-Closed
