6-10 Chapter 6
Configuring WAN Call Directory
The WAN Call Directory is a list of WAN Call Destination configurations to
use for each virtual circuit. You must create at least one WAN Call
Destination configuration for each destination. WAN Call Destination
configurations contain parameters to be applied by Emulex Frame Relay
software when establishing and maintaining calls to the destination.
Only permanent call configurations are supported in the current Emulex
Frame Relay implementation. This type of connection is suited for use with
dynamic routing protocols such as RIP or the NetWare Link Services
Protocol (NLSP) software.
1) If you are not already in the Internetworking Configuration menu, load
INETCFG from the server prompt:
Figure 6-3.Internetworking Configuration
2) Select WAN Call Directory , then press
The Configured Wan Call Destination window appears.
Figure 6-4. WAN Call Destinations
