SMA Solar Technology AG 4 Menu Overview
User Manual SPortal-WB-CLCON-BA-en-25 13
"Name of your plant"
> Grid Management This page will only be shown if in the plant a device is registered which
provides data on grid management (Cluster Controller or Power
Reducer Box). In the respective device, the use of Sunny Portal must be
activated and the settings for grid management carried out.
The page displays the following data:
• Diagrams with plant power and the specifications for active
power limitation stipulated by the network operator
• Table with reports from the plant logbook which are relevant for
grid management. Tip: Change to the plant logbook by selecting
"System Logbook".
• Diagrams with "active power limitation", "cos phi setpoint" and/
or "reactive power setpoint" by the network operator. Which
diagrams are shown depends on the operating mode of the
Cluster Controller/Power Reducer Box. In the case of a Power
Reducer Box, the different specifications for individual phases
can be represented by separate lines (L1, L2, L3).
"Name of your plant"
> Energy Balance This page is only displayed in plants with a Meter Connection Box.
The page displays the following data in a diagram depending on the
type of meter connected:
• Plant power
• Purchased electricity
• Self-consumption
"Name of your plant"
> Sensors This page is only shown if a Cluster Controller with connected sensors
is registered in the plant.
Depending on which sensors are connected, the page will show the
following data in diagrams:
• Irradiation
• Outside temperature and/or module temperature
Tip: If you disconnect the sensors from the Cluster Controller, the
data collected so far will remain visible.
"Name of your plant"
> Performance Ratio This page is only shown if a Cluster Controller with connected
irradiation sensor is registered in the plant.
The page shows the following data in diagrams:
• Daily performance ratio and irradiation values for the current
month
• Monthly performance ratio values for the current year
"Name of your plant"
> Annual Comparison The page shows the total yield and the specific yield of the active plant
per month in a yearly overview.
Menu Meaning
