626 14 Tables and Overviews
14.3 T
e
c
hnical Inf
o
rm
ation
Interpolation „ Line in 4 axes
† Line in 5 axes (subject to export permit) (software option 1)
„ Arc in 2 axes
 Arc in 3 axes with tilted working plane (software option 1)
„ Helix:
Combination of circular and linear motion
„ Spline:
Execution of splines (3rd degree polynomials)
Block processing time
3-D straight line without radius
compensation „ 3.6 ms
† 0.5 ms (software option 2)
Axis feedback control „ Position loop resolution: Signal period of the position encoder/1024
„ Cycle time of position controller: 1.8 ms
„ Cycle time of speed controller: 600 µs
„ Cycle time of current controller: minimum 100 µs
Traverse range „ Maximum 100 m (3973 inches)
Spindle speed „ Maximum 40 000 rpm (with 2 pole pairs)
Error compensation „ Linear and nonlinear axis error, backlash, reversal spikes during circular movements,
thermal expansion
„ Stick-slip friction
Data interfaces „ One each RS-232-C /V.24 and RS-422 / V.11 max. 115 kilobaud
„ Expanded data interface with LSV-2 protocol for remote operation of the TNC through
the data interface with the HEIDENHAIN software TNCremo
„ Ethernet interface 100 Base T
approx. 2 to 5 megabaud (depending on file type and network load)
„ USB 2.0 interface
For connection of pointing devices (mouse)
Ambient temperature „ Operation: 0 °C to +45 °C (32 °F to 113 °F)
„ Storage: –30 °C to +70 °C (–22 °F to 158 °F)
Accessories
Electronic handwheels „ One HR 420 portable handwheel with display or
„ One HR 410 portable handwheel or
„ One HR 130 panel-mounted handwheel or
„ Up to three HR 150 panel-mounted handwheels via HRA 110 handwheel adapter
Touch probes „ TS 220: 3-D touch trigger probe with cable connection, or
„ TS 640: 3-D touch trigger probe with infrared transmission
„ TT 130: 3-D touch trigger probe for workpiece measurement
Specifications
