HEIDENHAIN iTNC 530 381
8.6 SL Cy
cles
8 Milling depth Q1 (incremental value): Distance
between workpiece surface and contour floor.
8 Finishing allowance for side Q3 (incremental
value): Finishing allowance in the working plane.
8 Workpiece surface coordinate Q5 (absolute value):
Absolute coordinate of the workpiece surface
referenced to the workpiece datum.
8 Clearance height Q7 (absolute value): Absolute
height at which the tool cannot collide with the
workpiece. Position for tool retraction at the end of
the cycle.
8 Plunging depth Q10 (incremental value): Dimension
by which the tool plunges in each infeed.
8 Feed rate for plunging Q11: Traversing speed of the
tool in the tool axis.
8 Feed rate for milling Q12: Traversing speed of the
tool in the working plane.
8 Climb or up-cut ? Up-cut = –1 Q15:
Climb milling: Input value = +1
Up-cut milling: Input value = –1
To enable climb milling and up-cut milling alternately
in several infeeds:Input value = 0
