HEIDENHAIN iTNC 530 (340 49x-01) User Manual
Page 169
HEIDENHAIN iTNC 530
169
5.4 Thr
ee-Dimensional T
ool Compensation (Sof
tw
ar
e Option
2)
Example: Block format with rotary axes
1 L X+31.737 Y+21.954 Z+33.165
RL B+12.357 C+5.896 F1000 M128
L:
Straight line
X, Y, Z:
Compensated coordinates of the straight-line end point
L:
Straight line
B, C:
Coordinates of the rotary axes for tool orientation
RL
:
Radius compensation
M:
Miscellaneous function
