HEIDENHAIN iTNC 530 411
8.8 Cy
cles f
o
r Multipass Milling
8.8 Cycles for Multipass Milling
Overview
The TNC offers four cycles for machining surfaces with the following
characteristics:
„ Created with a CAD/CAM system
„ Flat, rectangular surfaces
„ Flat, oblique-angled surfaces
„ Surfaces that are inclined in any way
„ Twisted surfaces
Cycle Soft key
60 RUN 3-D DATA
For multipass milling of 3-D data in several infeeds
230 MULTIPASS MILLING
For flat rectangular surfaces
231 RULED SURFACE
For oblique, inclined or twisted surfaces
232 FACE MILLING
For level rectangular surfaces, with indicated oversizes
and multiple infeeds
