HEIDENHAIN iTNC 530 519
1
1
.8 A
d
ditional F
unctions
In the part program, program FN 16: F-PRINT, to activate the
output:
The TNC then outputs the file PROT1.TXT through the serial interface:
CALIBRAT. CHART IMPELLER CENTER GRAVITY
DATE: 27:11:2001
TIME: 8:56:34
NO. OF MEASURED VALUES : = 1
*******************************************
X1 = 149.360
Y1 = 25.509
Z1 = 37.000
*******************************************
L_ALL Display the text independent of the conversational
language
HOUR Number of hours from the real-time clock
MIN Number of minutes from the real-time clock
SEC Number of seconds from the real-time clock
DAY Day from the real-time clock
MONTH Month as a number from the real-time clock
STR_MONTH Month as a string abbreviation from the real-time
clock
YEAR2 Two-digit year from the real-time clock
YEAR4 Four-digit year from the real-time clock
96 FN16: F-PRINT TNC:\MASKE\MASKE1.A /
RS232:\PROT1.TXT
If you use FN 16 several times in the program, the TNC
saves all texts in the file that you have defined with the
first FN 16 function. The file is not output until the TNC
reads the END PGM block, or you press the NC stop
button, or you close the file with M_CLOSE.
In the FN16 block, program the format file and the log file
with their respective extensions.
If you enter only the file name for the path of the log file,
the TNC saves the log file in the directory in which the NC
program with the FN16 function is located.
Code word Function
