HEIDENHAIN iTNC 530 467
9.7 Defining the Mac
h
ining Plane with a Single, Incr
emental
Space
A
ngle:
P
LANE
RELA
TIVE
Input parameters
8 Incremental angle?: Spatial angle about which the
active machining plane is to be rotated additionally
(see figure at right). Use a soft key to select the axis
to be rotated about. Input range: –359.9999° to
+359.9999°
8 Continue with the positioning properties (see
“Specifying the Positioning Behavior of the PLANE
Function” on page 468).
Abbreviations used
Example: NC block
5 PLANE RELATIV SPB-45 .....
Abbreviation Meaning
RELATIV Relative
