HEIDENHAIN CNC PILOT 640 7
New functions of software 688945-03 and
68894x-01
 In the Organization mode of operation, you can grant or restrict
access to the control by using the EXTERNAL ACCESS soft key
(siehe auch „Organization mode of operation” auf Seite 542)
 The pocket calculator can now be activated in each application and
also remains active after a change in operating modes. The Get cur-
rent value
and Load current value soft keys enable you to fetch
numerical values from an active input field or to transfer them to an
active input field (siehe auch „Integrated calculator” auf Seite 58)
 Tool touch probes can now be calibrated in the Machine Setup
menu (siehe auch „Calibrating the tool touch probe” auf Seite 100)
 The workpiece zero point can now also be set in the direction of the
Z axis using a touch probe (siehe auch „Machine setup” auf Seite
92)
 In Teach-in mode, the oversizes RI and RK for the workpiece blank
were introduced for finishing in the recess-turning cycles (siehe
auch „Recess turning, radial finishing—expanded” auf Seite 250)
 The oversizes RI and RK for the workpiece blank were introduced for
finishing in the recess-turning units and in Cycle G869 (see
smart.Turn and DIN Programming User's Manual).
 On machines with a B axis it is now also possible to drill, bore, and
mill in oblique planes. In addition to this, the B axis enables you to
use tools even more flexibly during turning (see smart.Turn and DIN
Programming User's Manual).
 The control now provides numerous touch probe cycles for various
applications (see smart.Turn and DIN Programming User's Manual):
 Calibrating a touch trigger probe
 Measuring circles, circle segments, angle and position of the C
axis
 Misalignment compensation
 Single-point and double-point measurement
 Finding a hole or stud
 Zero point setting in the Z or C axis
 Automatic tool measurement
