HEIDENHAIN CNC PILOT 640 149
4.3 Single cut cy
cles
Linear machining at angle
Call the single-cut menu
Select linear machining at angle
 Off: When the cycle is completed, the tool remains
at the cycle end position.
 On: Tool returns to the starting point
Linear machining at angle
The CNC PILOT calculates the target position and moves the tool on a
straight line from the starting point to the target position at the
programmed feed rate. When the cycle is completed, the tool remains
at the cycle end position.
