246 Teach-in mode
4.5 Recessing cy
cles
Recess turning, radial finishing
Call the recessing cycles
Select recess turning
Select recess turning, radial
Press the Finishing run soft key
The cycle finishes the contour area defined by the starting point and
contour end point
(see also “Recess turning” auf Seite 238).
With oversizes I, K, you define the material left
remaining after the finishing cycle.
Cycle parameters
X, Z
Starting point
X2, Z2 Contour end point
I, K Oversize X, Z
G14 Tool change point (siehe Seite 140)
T Turret pocket number
ID Tool ID number
S Spindle speed/cutting speed
F Feed per revolution
G47 Safety clearance (siehe Seite 140)
MT M after T: M function that is executed after the tool call T.
