HEIDENHAIN CNC PILOT 640 623
9.3 T
e
c
hnical inf
o
rm
ation
Tool database  For 250 tools
 For 999 tools (optional)
 Tool description can be entered for every tool
 Automatic inspection of tool-tip position with respect to the contour
 Compensation of tool-tip position in the X/Y/Z plane
 High-precision correction via handwheel, capturing compensation
values in the tool table
 Automatic tool-tip and cutter radius compensation
 Tool monitoring for lifetime of the insert (tool tip) or the number of
workpieces produced
 Tool monitoring with automatic tool change after tool insert wear
(optional)
 Management of multipoint tools (multiple inserts or reference
points)
Technology database (optional)  Access to cutting data after definition of workpiece material, cutting
material and machining mode. The CNC PILOT distinguishes
between 16 machining modes. Each workpiece-material/tool-
material combination includes the cutting speed, the main and
secondary feed rates, and the infeed for 16 machining modes.
 Automatic determination of the machining modes from the cycle or
the machining unit
 The cutting data are entered in the cycle or in the unit as default
values.
 9 workpiece-material/tool-material combinations (144 entries)
 62 workpiece-material/tool-material combinations (992 entries)
(optional)
User functions
