Knurling tool, 3 t ool data – HEIDENHAIN SW 68894x-03 User Manual
Page 532
532
Tool and technology database
7.
3 T
ool data
Knurling tool
Select "New tool."
Select special tools.
Select knurling tool.
The help graphics illustrate the dimensions of the tools.
Special parameters for knurling tools
SL
Cutting length
EW
Tool angle
SB
Cutting width
DN
Tool width
SD
Shank diameter
For further tool parameters, see Seite 516.
