HEIDENHAIN CNC PILOT 640 643
1
0
.2 T
u
rn
ing cy
cles
10.2 Turning cycles
Turning cycles Page
Overview 158
Cut longitudinal
Roughing and finishing cycle for simple
contours 161
Cut transverse
Roughing and finishing cycle for simple
contours 163
Cut with longitudinal plunge
Roughing and finishing cycle for
simple contours 175
Cut with transverse plunge
Roughing and finishing cycle for simple
contours 177
ICP contour-parallel, longitudinal
Roughing and finishing cycle for any
type of contour 191
ICP contour-parallel, transverse
Roughing and finishing cycle for any
type of contour 194
ICP cut longitudinal
Roughing and finishing cycle for any
type of contour 200
ICP cut transverse
Roughing and finishing cycle for any
type of contour 202
