77
Kaleido-X (7RU)
Hardware Description & Installation Manual
These cards support one SDTI audio input.
KXA-GPI-GEN Card
This card supports a reference input for system genlock.
KXO-Dual / KXO-Dual3 Cards
These cards support two DVI-D inputs for background graphics:
These cards support one LTC unbalanced input for clock synchronization:
SDTI Audio Inputs
Signal SMPTE ST 305:2005 (up to 128 channels/64 AES)
Cable length 250 m (820 ft) (Belden 1694A)
Connector BNC
Reference Inputs
Supported formats SMPTE ST 170
SMPTE ST 318
ITU 624-4
BUT 470-6
PAL and NTSC composite sync
SMPTE ST 274
SMPTE ST 296
SMPTE ST 240
Connector BNC
DVI-D Inputs
Signal DVI-D
Resolution From 1024 × 768 to 1920 × 1200 NI
H frequency 37 kHz to 96 kHz
Refresh rate 50/59.94 Hz
Cable length 3.6 m (12 ft) with Altinex CB4012DV
Connectors DVI-I
LTC Unbalanced Input
Signal SMPTE ST 309:1999, SMPTE ST 12:1995 (EBU-3259-E)
Level 500 mVp-p to 10 Vp-p
Impedance >10 k
Connector BNC
Ω
