54
Kaleido-X (14RU) Expansion
Expanding EXISTING Kaleido-X Frames
• to copy/paste monitors between layouts/displays.
• to reassign a layout to a different room.
• to save two or more rooms that are using the same heads.
The table below describes the state of the database following a merge:
At this point, you can begin to restore the missing settings and bring the database up to
date by:
• creating new rooms or modifying existing ones to reflect the new expansion
configuration
• resolving duplicate head assignments
• copying old layouts into new expansion ones
To modify a room
1 Open the room you wish to modify.
Database Element Frame A Frame B Comments
System
configuration NO NO Must be recreated manually, prior to database
merge
Peripheral device
settings YES NO
External router
settings NO NO
Rooms YES YES Duplicate head assignments must be resolved
Layouts YES YES
Full screen layouts YES YES
Full screen zones YES YES
Logical sources YES YES Some logical sources may be duplicated. Signals
from the two frames are identified with prefix F1
(Frame 1=master) and F2 (frame 2=slave) in order to
track the assignments in XEdit and on the monitor
wall. Example: F1MA I2 = Frame 1, Module A, Input 2
Levels YES YES
Monitors YES YES
Images YES YES
Actions YES YES Actions associated with monitors in a layout are
preserved
Background actions YES NO Introduced with Kaleido-X version 3.00
RCP users YES NO
Resolutions YES NO
Calibrations YES NO
Timers YES NO
Audio scales YES NO
