Specifications
KXI-16HSV, KXI-16HS, KXI-16SV, KXI-16HSV3, and KXI-16HS3
HD-SDI Inputs (KXI-16HSV3, KXI-16HSV, KXI-16HS3, KXI-16HS)
Signal 4:2:2 SMPTE ST 292-C (1.5 Gbps)
Formats 720p24, 720p25, 720p29.97, 720p50, 720p59.94
1080i50, 1080i59.94
1080PsF23.98, 1080PsF24, 1080PsF25, 1080PsF29.97
1080p23.98, 1080p24, 1080p25, 1080p29.97
Note: The Kaleido-X software does not distinguish
between 1080PsF25 and 1080i50, and neither between
1080PsF29.97 and 1080i59.94. Both 1080PsF25 and
1080i50 are reported as 1080i50, and both 1080PsF29.97
and 1080i59.94 are reported as 1080i59.94, on the
monitor wall and in XAdmin’s Status and Options page.
Audio SMPTE ST 299
Return loss > 12 dB up to 1.485 GHz
Jitter < 0.2 UI
Cable length 100 m (328 ft) (Belden 1694A)
3G-SDI Inputs (KXI-16HSV3, KXI-16HS3)
Signal 4:2:2 SMPTE ST 424:2006 (2.97, 2.97/1.001 Gbps)
Formats SMPTE ST 425:2008 level A and level B (single stream)
1080p50
1080p59.94
Audio SMPTE ST 299
Return loss > 15 dB up to 1.5 GHz
> 10 dB up to 2.97 GHz
Jitter < 0.2 UI
Cable length 100 m (328 ft) (Belden 1694A)
Graphic converted to HD-SDI from KXI-DVI-Bridge
Signal SMPTE ST 292-C (1.485, 1.485/1.001 Gbps)
Formats 1024 × 768 @ 60 (XGA)
1280 × 1024 @ 60 (SXGA)
1366 × 768 or 1368 × 768 @ 60 (WXGA)
1680 × 1050 @ 60 (WSXGA+)
1600 × 1200 @ 60 (UXGA)
Cable length 100 m (328 ft) (Belden 1694A)
