2 Open a room and locate the display with a duplicate head assignment.
3 Expand the filtered System list in the Tools pane, and then drag the appropriate output
head onto the display whose assignment you wish to rectify.
The new head assignment information appears. In the System list, the red text turns
black.
4 Repeat step 2 and step 3 until all duplicated head assignments have been resolved.
To copy old layouts into new expansion ones
1 Open an existing layout.
2 On the File menu, click Copy layout to, specifying a target room and layout.
Conflicting assignments
marked in rd
Conflict resolved
