2. Configure XRE Monitor settings as follows:
a) From the Windows desktop, click Start | All Programs | Grass Valley | XREMonitor .
The XREMonitor window opens.
b) Click Setting .
The Settings dialog box opens.
c) In the tree view, click Settings | Server settings .
d) Click Add .
The Server setting dialog box opens.
e) Make XRE Monitor settings, as follows.
Table 14: XRE Monitor settings
Value Setting
Name: The XRE Server name. It is recommended that you enter
the machine name.
Address: The XRE Server IP address.
Port: The port assigned for communication with the EDIUS XRE
Server, as specified in GV STRATUS Control Panel EDIUS
Settings. The default port number is 1223.
Server setting
f) Click OK and Apply to save settings and close.
460 GV STRATUS Installation and Service Manual 2013 12 19
Complete system set up and configuration
