Specification Characteristic
450W typical (standalone)
390W typical (SAN client)
Maximum AC current 8A @ 115VAC, 4A @
230VAC
Maximum power consumption (when operating
in a 25° C environment)
K2 RAID Rack specifications
Use the following specifications to determine load, spacing, power, and other factors when planning
system racks. These specifications apply to K2 10Gv2 RAID (M100) chassis.
Table 7: Mechanical specifications
Expansion chassis Primary chassis Characteristic
Rack-mount Rack-mount Cabinet Type
2 2 Rack units
482 x 513.2 x 87.8 mm (no front
bezel) 482 x 513.2 x 87.8 mm (no front
bezel) External Dimensions
29 kg maximum 31 kg maximum Weight
Table 8: Power specifications
Primary chassis Primary chassis Characteristic
100 to 240 VAC, single-phase
50/60 Hz 100 to 240 VAC, single-phase
50/60 Hz Power conditions
290 W 400 W Maximum power consumption
(when operating in a 25° C
environment)
FT Server Rack specifications
Use the following specifications to determine load, spacing, power, and other factors when planning
system racks.
Table 9: Mechanical specifications
Type I and Type II Specification Characteristic
Rack-mount Cabinet Type
4 Rack units
483 (w) x 178 (h) x 736 (d) mm, 19.0 in. (w) x 7.0 in. (h) x 28.9 in. (d) External Dimensions
30 GV STRATUS Installation and Service Manual 2013 12 19
Commissioning a system
