Type I and Type II Specification Characteristic
40 cm or more on top, 1 m or more on the front and rear, 60 cm or more
on the right and left. Rack clearance
Maximum 51.5kg , 113.3 lbs Weight
Table 10: Power specifications
Type II Specifications Type I Specifications Power Supply
AC 100V-240V +/- 10%, 50/60Hz +/-
3Hz AC 100V-240V +/- 10%, 50/60Hz +/-
3Hz Type
1300VA, 1290W 1400VA, 1390W Power
Consumption
Securing a server to a rack
If the server is a Dell server, follow the instructions provided in the shipping box to install the rack
rails and position the server in the rack. For the Dell 1RU PowerEdge Server, follow the illustration
below to secure the system to the rack.
Install a screw in the bottom hole of the bracket on each side. Do not attempt to install a screw in
the top hole of the bracket.
Cable K2 systems
All systems require this process.
Cable the K2 systems that store and serve your high-resolution assets. This includes any K2 SAN
systems and K2 standalone systems in your system design.
2013 12 19 GV STRATUS Installation and Service Manual 31
Commissioning a system
