Grass Valley GV STRATUS Installation v.3.1 - Manual (Page 103)

Description Setting or button
A name for this instance of the MDI type. Do not use spaces in the
MDI name. MDI Name
The name of the GV STRATUS server on which this MDI runs and
which is managed by this MDI. Typically this is the Proxy Encoder
itself. If an Express system with no Proxy Encoders, this is the Express
server. Hostname of device
running the MDI
For the first encoder, port 9230 is required. For any additional Proxy
Encoders, the port number is automatically incremented. For example,
for the second encoder the port number is 9231. Port number
The MDI for the K2 Summit/SAN system with the high resolution
assets. Source MDI
If a GV STRATUS system with K2 Summit SAN-attached systems
only, the FTP Server is the Proxy Encoder itself. If a GV STRATUS
system with a K2 Summit standalone system, the FTP server is the K2
Summit standalone system. FTP Server
Related Topics
MDI and Encoder logical names convention on page 183
Configuring Proxy Encoder MDI settings: Optional on page 405
Proxy Encoder iSCSI client requirement on page 160
STRATUS Core Services Metadata settings
These settings are optional on GV STRATUS systems.
To locate these settings, click Core | Metadata | Custom Metadata
2013 12 19 GV STRATUS Installation and Service Manual 103
Reference to GV STRATUS Control Panel settings
