Appendix D Use of Application Instructions|DOP-EXIO Series
D-36
Revision March, 2008, Doc. Name: 2007PDD23000014
Program Example 1:
When X0 = On, D0 will be divided by D10 and the quotient will be stored in D20 and remainder in D21.
On/Off of the highest bit indicates the positive/negative status of the result value.
X0
DIV
D0
D10
D20
D0
D10
K4Y0
DIV
Program Example 2:
When X0 = On, (D1, D0) will be divided by (D11, D10) and the quotient will be stored in (D21, D20) and
remainder in (D23, D22). On/Off of the highest bit indicates the positive/negative status of the result
value.
X0
DDIV
D0
D10
D20
D0
D10
K8Y0
DDIV
