Page 88
Atlas Diagrams
Foundation Diagrams
Page A-12 MDE-4331M Atlas® Fuel Systems Installation Manual · September 2014
Figure A-11: Self-contained Pump - SHF Model
Model Numbers
9140K/9140K-S
9840K/9840K-S
Side 1 Nozzle Boot (Front Load Units)
Side 1 Nozzle Boot
(Side Load Units)
Anchor Bolt Slots (Use 1 minimum each side)
1-inch NPT Conduit Connection AC Power
1-1/4-inch NPT Discharge to Satellite
3/4-inch NPT Conduit Connection AC Power
Footprint
Self-contained Pump - SHF Models
Discharge to Satellite
Product Inlet
AC Power Connection
Optional DC Power Connection
