MDE-4331M Atlas® Fuel Systems Installation Manual · September 2014 Page 6-1
Purpose Installation
6 – Installation
Purpose
This section provides information specific to the installation of Atlas pumps/dispensers.
Required Equipment and Materials
DEF is not flammable or explosive. Therefore, installation requirements for DEF units differ
from units that handle hazardous fuels. However, electrical safety requirements are applicable.
When installing a DEF unit in a hazard zone defined by the location of another

pump/dispenser handling hazardous fuels, the area of the DEF dispenser within the hazard
zone must conform to requirements for units handling hazardous fuels.
Following items are required for the installation of the equipment:
• Anchor bolts
• UL-approved sealant (for use with fuels being encountered)
• Pit box cover plates (for use when it is required to adapt the unit to pre-existing pit boxes)
• Lifting device (forklift) to move and lift pumps/dispensers
• Breakaways, hoses, nozzles, and swivels
• Approved wire nuts
• Barricades
• Potting compound and fiber dam material (to allow potting of conduit as per class I,
division II locations, as specified in the NEC)
Important Requirements for E85 Units
Following equipment and materials are required to properly install E85 units:
UL-listed E85 Hose (Q13486)
• Veyance SM Flexsteel ™ Futura ® Ethan-All for E85
• Veyance Flexsteel Futura for E25
Note: Extended reach hoses are not available for the E85 applications.
UL-listed E85 Nozzle (M11298)
OPW
® 21GE
Note: Approved for use with the E85 dispensers, as required under UL 87A.
UL-listed E85 Swivel (N23748-04)
OPW 241 TPS-0492
Note: Approved for use with E85 dispensers, as required under UL 87A.
