Preparing for Installation
Installation
3
Check the following for proper installation, as per the criteria specified in MDE-4333 Atlas
Fuel Systems Site Preparation Manual, and other manufacturer’s recommendations that apply:
• Emergency Power Cut-off Switch
• Circuit Breakers
• STP Control Relay Boxes - Dispensers only (see
)
• Isolation Relays - Dispensers only (see
• Breakaways, hoses, nozzles, and swivels (refer to
“Installing Breakaways, Hoses, Swivels,
)
• Conduit and Wiring (see
• Grounding
• Shear Valves - Dispensers only (see
• Piping and Fittings
• Fuel Storage Tanks
• Pressure Regulating Valves (aboveground tanks only)
• STP - Dispensers only
• Tank and/or Line Leak Detectors
• Pit Boxes
Notes: 1) A shear valve is an NFPA 30A recommended safety device required for every
product line at each dispenser. For installation instructions, refer to MDE-4333
Atlas Fuel Systems Site Preparation Manual. Shear valves may also be required
for aboveground tank installations and other situations with pumps. Consult
local and state requirements.
2) Refer to MDE-4334 Commercial and Retail Series Atlas Start-up/Service
Manual.
3) Some locations require shear valves for vapor lines. Consult local and state
regulations.
4) The 9862 Atlas DEF units uses a special stainless steel shear valve made by
OPW.
4
Inspect the pump/dispenser cartons and contents for shipping damage. Gasboy does not cover
shipping damage under its warranty policy. Notify the shipper of any damage.
5
Remove the bezel and lower panels (doors) of the pump/dispenser, refer to MDE-4334
Commercial and Retail Series Atlas Start-up/Service Manual.
6
Ensure that the fuel grade for product lines matches the pump/dispenser brand panels and
foundation layout. Product lines from the island pit box must have labels.
