MDE-4331M Atlas® Fuel Systems Installation Manual · September 2014 Page A-3
Foundation Diagrams Atlas Diagrams
Foundation Diagrams
This section lists the details of the foundation diagrams:
Register Flow Rating Pump/Disp Type
Atlas Commercial
Model
Atlas Retail Model
MDE-4331 Foundation Figure
Basic
with Satellite
Piping (S)
Mech SF Disp Single 9152KX 8752KX Figure A-3 Figure A-7
Mech SF Disp TW1 9152KXTW1 8752KXTW1 Figure A-3 Figure A-10
Mech SF Disp TW2 9152KXTW2 8752KXTW2 Figure A-4 Figure A-8
Mech SF Pump Single 9152K 8752K Figure A-5 N/A
Mech SF Pump TW1 9152KTW1 8752KTW1 Figure A-5 N/A
Mech SF Pump TW2 9152KTW2 8752KTW2 Figure A-6 N/A
Mech HF Disp Single 9153KX 8753KX Figure A-3 Figure A-7
Mech HF Disp TW1 9153KXTW1 8753KXTW1 Figure A-3 Figure A-10
Mech HF Disp TW2 9153KXTW2 8753KXTW2 Figure A-4 Figure A-8
Mech HF Pump Single 9153K 8753K Figure A-5 N/A
Mech HF Pump TW1 9153KTW1M 8753KTW1M Figure A-9 N/A
Mech HF Pump TW2 9153KTW2 8753KTW2 Figure A-6 N/A
Mech SHF Disp Single 9140KX N/A Figure A-12 Figure A-12
Mech SHF Pump Single 9140K N/A Figure A-11 Figure A-11
Elec SF Disp Single 9852KX 8852KX Figure A-3 Figure A-7
Elec SF Disp TW1 9852KXTW1 8852KXTW1 Figure A-3 Figure A-10
Elec SF Disp TW2 9852KXTW2 8852KXTW2 Figure A-4 Figure A-8
Elec SF Pump Single 9852K 8852K Figure A-5 N/A
Elec SF Pump TW1 9852KTW1 8852KTW1 Figure A-5 N/A
Elec SF Pump TW2 9852KTW2 8852KTW2 Figure A-6 N/A
Elec HF Disp Single 9853KX 8853KX Figure A-3 Figure A-7
Elec HF Disp TW1 9853KXTW1 8853KXTW1 Figure A-3 Figure A-10
Elec HF Disp TW2 9853KXTW2 8853KXTW2 Figure A-4 Figure A-8
Elec HF Pump Single 9853K 8853K Figure A-5 N/A
Elec HF Pump TW1 9853KTW1M 8853KTW1M Figure A-9 N/A
Elec HF Pump TW2 9853KTW2 8853KTW2 Figure A-6 N/A
Elec SHF Disp Single 9840KX N/A Figure A-12 Figure A-12
Elec SHF Pump Single 9840K N/A Figure A-11 Figure A-11
Elec UHF Disp Single 9850KX N/A Figure A-15 Figure A-15
Elec UHF Disp TW1 9850KXTW1 N/A Figure A-18 Figure A-18
Elec UHF Disp TW2 9850KXTW2 N/A Figure A-17 Figure A-17
Elec UHF Disp TW3 9850KXTW3 N/A Figure A-16 Figure A-16
Elec UHF Pump Single 9850K N/A Figure A-13 Figure A-13
Elec UHF Pump TW3 9850KTW3 N/A Figure A-14 Figure A-14
Elec SF Disp (E85) TW1 9872KX,
9872KXTW1 N/A Figure A-19 Figure A-19
Elec SF Disp (DEF) TW1 9862KX N/A Figure A-20 N/A
Elec SF Disp (DEF) TW1 9862KX-WW N/A Figure A-21 N/A
