MD2401 L-Band Multi Demod Installation and Operation Manual

Technical Specifications

MN-MD2401

7–6

Revision 7

7.7.4 BER Performance (8PSK Trellis)

1E-9

1E-8

1E-7

1E-6

1E-5

1E-4

1E-3

1E-2

1E-1

0

1

2

3

4

5

6

7

8

9

10

11

12

Eb/No in dB

BE

R

Trellis

Decoder

Specification

2/3 Rate

Specification

2/3 Rate w/RS

Typical

Performance

8PSK Uncoded Theory

Figure 7-4 - MD2401 8PSK BER Performance (Trellis)

Note: Eb/No values include the effect of using differential decoding and v.35 descrambling.
