8 md2401 input level – Comtech EF Data MD2401 User Manual
Page 102
MD2401 L-Band Multi Demod Installation and Operation Manual
Technical Specifications
MN-MD2401
7–12
Revision 7
7.8
MD2401 Input Level
MD2401 Input Level
-80
-70
-60
-50
-40
-30
-20
1
10
100
1000
10000
Symbol Rate (kHz)
Input
Le
v
e
l (
dB
m
)
High Input Level Limit
Low Input Level Limit
64 kSPS
640 kSPS
Figure 7-8. MD2401 Input Level
