MD2401 L-Band Multi Demod Installation and Operation Manual
User Interfaces
MN-MD2401
4–21
Revision 7
<1>
<1>
<1>
<24>
<1>
<1>
*<1>
<1>
<1>
*<1>
*<1>
*<1>
*<1>
Common Alarm 1
Mask
Reserved
BER Measure
Period
Rx Circuit ID
Rx Terrestrial
Loopback
Rx Baseband
Loopback
Rx IF Loopback
Reserved
Data Invert
Async Framing
Async Baud Rate
Async Port Type
Async Terrestrial
Interface Type
Bit 2 = Rx Satellite Clock Activity Detect Fault
Bit 3 = External Reference PLL Activity Fault
Bit 4 = High Stability Activity Detect Fault
Bit 5 = High Stability PLL Fault
Bit 6 = Eb/No Threshold Fault
Bit 7 = Spare
(0 = Mask, 1 = Allow)
Bit 0 = -12 V Alarm
Bit 1 = +12 V Alarm
Bit 2 = +5 V Alarm
Bit 3 = Temperature
Bit 4 = Interface FPGA Fault
Bit 5 = Battery Fault
Bit 6 = RAM/ROM Fault
Bit 7 = Spare
(0 = Mask, 1 = Allow)
Set to Zero
Unsigned Binary Number of Bits in Measurement Period, in Powers
of Ten (ex: 6 = 10
6
Bits)
24 ASCII Characters
0 = Disabled, 1 = Enabled
0 = Disabled, 1 = Enabled
0 = Disabled, 1 = Enabled
Ignore
0 = Normal, 1 = Invert
Note: The following byte applies only if an Asynchronous, IDR
or IBS Interface is installed. If not, ignore.
0 = No Framing, 1 = 1/16 Async, 2 = 1/16 IBS, 3 = 96 Kbit IDR
Note: The following byte applies only if an asynchronous
interface card is installed. If not, ignore.
0 = 1200, 1 = 2400, 2 = 4800, 3 = 9600, 4 = 19200, 5 = 50, 6 = 110,
7 = 300, 8 = 600
Note: The following byte applies only if an asynchronous
interface card is installed. If not, ignore.
0 = RS-232, 1 = RS-485
Note: The following byte applies only if an asynchronous
interface card is installed. If not, ignore.
0 = V.35, 1 = RS-422, 2 = RS-232
