MD2401 L-Band Multi Demod Installation and Operation Manual User Interfaces
MN-MD2401 4–30
Revision 7
<1>
<1>
<1>
<1>
*<1>
*<1>
*<1>
<1>
*<1>
*<1>
BER/EbNo
Status
Buffer Percent
Full
Input Level
Input Level State
Alarm 5
Backward Alarms
Latched Alarm 5
Control Mode
Insert Alarms
Insert Back Alarm
Bit 0 = Raw BER and Corrected BER Status (1 = Valid)
Bit 1 = Test 2047 BER Status (1 = Valid)
= EbNo Status (0 = EbNo is Invalid, 1 = EbNo is Valid, 2 = EbNo is
Smaller Than Indicated Value, 3 = EbNo is Greater Than Indicated
Value)
Bit 4 = Raw BER Counter Overflow (1 = overflow condition)
Bit 5 = Test 2047 BER Counter Overflow (1 = overflow condition)
Bits 6 & 7 = Spares
Unsigned Binary Value Representing % Buffer Full (0 - 100 in 1%
steps)
Unsigned Binary Value in -1 dB Steps, Negative Sign Implied
Signed Binary (0 = Equal to, 1 = Greater Than, -1 = Less Than Value
in -1 dB Steps, Negative Sign Implied)
Bit 0 = IBS/IDR Satellite Multiframe Sync Loss
Bit 1 = IBS/IDR Satellite Frame Sync Loss
Bit 2 = Spare
Bit 3 = IBS BER Alarm
Bit 4 = IBS Prompt Alarm
Bit 5 = IBS Service Alarm
Bit 6 = Turbo Codec Lock Fault
Bit 7 = Spare
(0 = Pass, 1 = Fail)
Bit 0 = IBS Backward Alarm or IDR Backward Alarm 1
Bit 1 = IDR Backward Alarm 2
Bit 2 = IDR Backward Alarm 3
Bit 3 = IDR Backward Alarm 4
Bits 4 - 7 = Spares
(0 = Pass, 1 = Fail)
Bit 0 = IBS/IDR Satellite Multiframe Sync Loss
Bit 1 = IBS/IDR Satellite Frame Sync Loss
Bit 2 = Spare
Bit 3 = IBS BER Alarm
Bit 4 = IBS Prompt Alarm
Bit 5 = IBS Service Alarm
Bit 6 = Turbo Codec Lock Fault
Bit 7 = Spare
(0 = Pass, 1 = Fail)
0 = Front Panel, 1 = Terminal, 2 = Computer RLLP
Bit 0 = Frame Lock Fault
Bit 1 = Multiframe Lock Fault
Bit 2 = CRC Lock Fault. Valid only in T1-ESF and E1 – CRC enabled
Bit 3 = T1 Yellow Alarm Received
Bit 4 = E1 FAS Alarm Received
Bit 5 = E1 MFAS Alarm Received
Bit 6 = E1 CRC Alarm Received
Bit 7 = CRC Calculation Fault
(0 = Pass, 1 = Fail)
Bit 0 = Backward Alarm Received from Satellite
