MD2401 L-Band Multi Demod Installation and Operation Manual User Interfaces
MN-MD2401 4–44
Revision 7
<1>
<1>
Month
Day
0 – 11
0 - 30
Opcode: <2C06h>
Command Set Time and Date
<1>
<1>
<1>
<1>
<1>
<1>
Year
Month
Day
Hour
Minute
Second
0 – 99
0 – 11
0 – 30
0 – 23
0 – 59
0 – 59
Opcode: <2C07h>
Command soft reset the modem to the power-up state (no parameters).
Opcode: <2C08h> Commend Eb/No Threshold
<1> Eb/No Threshold Unsigned Binary Value, 0-99, Implied Decimal Point
0.0 through 9.9 dB
Opcode: <2C30h>
Command Module Set Default Configuration (No Parameters)
4.8 4.4.12.3 Default Values Demodulator
Opcode: <2A00h> Command a Demodulator’s Configuration
<4>
<4>
<1>
<4>
<1>
<1>
<1>
<1>
Frequency
Data Rate
Sweep Boundary
External
Reference
Ext Reference
Source
Input Level Limit
Demodulation
Type
Convolutional
Decoder
70,000,000 Hz
140,000,000 Hz (**)
950,000,000 Hz
(Hardware dependant)
**Legacy 100-180 MHz only
2,048,000 BPS
25 kHz
10,000,000 Hz
0 = Internal
-90 dBm
0 = QPSK
1 = Viterbi ½ Rate <04> <2C> <1D> <80>
<08> <58> <3B> <00>
<38> <9F> <80>
<00> <1F> <40> <00>
<19>
<00> <98> <96> <80>
<00>
<5A>
<00>
<01>
