MD2401 L-Band Multi Demod Installation and Operation Manual User Interfaces
MN-MD2401 4–36
Revision 7
<1>
<1>
<24>
<1>
<1>
*<1>
<1>
<1>
*<1>
*<1>
*<1>
*<1>
*<1>
Reserved
BER Measure
Period
Rx Circuit ID
Rx Terrestrial
Loopback
Rx Baseband
Loopback
Rx IF Loopback
Reserved
Data Invert
Framing
Async Baud Rate
Async Port Type
Async Terrestrial
Interface Type
Multiprotocol
Interface Card
Interface Type
Bit 4 = Interface FPGA Fault
Bit 5 = Battery Fault
Bit 6 = RAM/ROM Fault
Bit 7 = Spare
(0 = Mask, 1 = Allow)
Set to Zero
Unsigned Binary Number of Bits in Measurement Period in Powers of
Ten (ex: 6 = 10
6
Bits)
24 ASCII Characters
0 = Disabled, 1 = Enabled
0 = Disabled, 1 = Enabled
0 = Disabled, 1 = Enabled
Set to Zero
0 = Normal, 1 = Invert
Note: The following byte applies only if an Asynchronous, IDR or
IBS Interface is installed. If not, set to zero.
0 = No Framing, 1 = 1/16 Async, 2 = 1/16 IBS, 3 = 96 Kbit IDR
Note: The following byte applies only if an asynchronous
interface card is installed. If not, set to zero.
0 = 1200, 1 = 2400, 2 = 4800, 3 = 9600, 4 = 19200, 5 = 50, 6 = 110, 7
= 300, 8 = 600
Note: The following byte applies only if an asynchronous
interface card is installed. If not, set to zero.
0 = RS-232, 1 = RS-485
Note: The following byte applies only if an asynchronous
interface card is installed. If not, set to zero.
0 = V.35, 1 = RS-422, 2 = RS-232
Note: The following byte applies only if a synchronous
Multiprotocol interface card is installed. If not, set to zero.
0 = V.35, 1 = RS-422, 2 = RS-232
Note: The following byte applies only if a symmetric G.703
interface card is installed. If not, set to zero.
