FRU Installation

Centellis 2000 Shelf - DC Installation and Use (6806800G45F)

The following figure shows the ATCA-MF105 shelf manager and hub board.

Figure 4-1

ATCA-MF105

Damage of Circuits
Electrostatic discharge and incorrect installation and removal of the product can damage
circuits or shorten their life.
Before touching the product make sure that your are working in an ESD-safe environment
or wear an ESD wrist strap or ESD shoes. Hold the product by its edges and do not touch any
components or circuits.
