Technical Data
Centellis 2000 Shelf - DC Installation and Use (6806800G45F)
167
B.2.3
Fan Tray Replacement
Table B-7 Airflow Summary during Front Fan Tray Replacement
Chassis
Front Blade (FB)
RTM
Total
86.4 CFM
72.4 CFM
14.1 CFM
Maximum
-
36.7 CFM
7.5 CFM
Minimum
-
35.7 CFM
6.6 CFM
Average
-
36.2 CFM
7.0 CFM
Table B-8 Quadrant Detail during Front Fan Tray Replacement
FBQ1
FBQ2
FBQ3
FBQ4
FB Total
RTM
Slot 1
8.7 CFM
8.8 CFM
9.3 CFM
9.9 CFM
36.7 CFM
6.6 CFM
Slot 2
8.8 CFM
8.9 CFM
8.4 CFM
9.9 CFM
35.7 CFM
7.5 CFM
Figure B-6
Front Blade Slot Volumetric Flow during Front Fan Tray Replacement
