Network Management and System Access
Centellis 2000 Shelf - DC Installation and Use (6806800G45F)
133
Virtual Standby IP Address on Out-of-Band Interface
To avoid an address conflict between out-of-band and backplane interfaces, 100 is added to
the third octet of all out-of-band interface IP addresses, if any of them would be equal to one of
the backplane addresses otherwise.
Changing the Shelf Manger Virtual IP Address for the Out-of-Band Interface
To change this IP address, you must modify the first two octets of the Shelf IP Connectivity
Record #1 and/or change the shelf address. Refer to
Setting the Shelf Geographical Address
to see how you can change the shelf address. This procedure describes how to
change the first two octets of the IP address.
1. Change the first two octets of the IP address using the hpiship tool located on the
shelf manager. Use the option -h for help.
2. Reboot the system for the changes to take effect.
Example #1:
Print current IP address settings and change out-of-band address:
*Print current IP address settings
shm9s8:~ # hpiship
29 {ADVANCEDTCA_CHASSIS,9} Shelf Resource
4097 Shelf Manager IP Address 0
IP : 192.168.9.171
Gateway: 192.168.9.0
Submask: 255.255.255.0
Netmask of IP1
Virtual Standby IP Address
Default Value
255.0.0.0
192.168.0.181
255.255.0.0
255.255.255.0
