Technical Data
Centellis 2000 Shelf - DC Installation and Use (6806800G45F)
163
B.2
Airflow Data
The following sections summarize the airflow data of the system.
B.2.1
Full Speed Operation
Table B-3 Airflow Summary at Full Speed Operation
Chassis
Front Blade (FB)
RTM
Total
109.7 CFM
93.8 CFM
15.9 CFM
Maximum
-
47.4 CFM
8.1 CFM
Minimum
-
46.4 CFM
7.8 CFM
Average
-
46.9 CFM
8.0 CFM
Table B-4 Quadrant Detail at Full Speed Operation
FBQ1
FBQ2
FBQ3
FBQ4
FB Total
RTM
Slot 1
12.0 CFM
11.6 CFM
11.3 CFM
11.4 CFM
46.4 CFM
7.8 CFM
Slot 2
12.2 CFM
11.0 CFM
11.9 CFM
12.3 CFM
47.4 CFM
8.1 CFM
