Network Management and System Access
Centellis 2000 Shelf - DC Installation and Use (6806800G45F) 126
Access via the face plate interface:
Access via base interface channel 1:
Access via base interface channel 2:
For further information on the IP addresses of the ATCA-MF105, refer to section IP Addresses on
page 130 .
8.3 Network Management
When you need to access system components, there are various network addresses you need
to be aware of. The following subsections describe the default addresses and if and how they
can be changed.
ATCA-MF105 IP Address
Left ATCA-MF105 192.168..8
Right ATCA-MF105 192.168..9
Active ATCA-MF105 192.168..171
Standby ATCA-MF105 192.168..181
ATCA-MF105 IP Address
Left ATCA-MF105 172.17..8
Right ATCA-MF105 172.17..9
Active ATCA-MF105 172.16..171
Standby ATCA-MF105 172.16..181
ATCA-MF105 IP Address
Left ATCA-MF105 172.18..8
Right ATCA-MF105 172.18..9
Active ATCA-MF105 172.16..171
Standby ATCA-MF105 172.16..181
