Technical Data
Centellis 2000 Shelf - DC Installation and Use (6806800G45F)
165
B.2.2
Single/Multiple Fan Failure
Airflow data for the front left failure condition is worse than for any other single fan failure, and
that data is presented in this section.
Table B-5 Airflow Summary for a Single/Multiple Fan Failure
Chassis
Front Blade (FB)
RTM
Total
84.5 CFM
70.2 CFM
14.3 CFM
Maximum
-
35.2 CFM
7.5 CFM
Minimum
-
35.1 CFM
6.8 CFM
Average
-
35.1 CFM
7.2 CFM
Table B-6 Quadrant Detail for a Single/Multiple Fan Failure
FBQ1
FBQ2
FBQ3
FBQ4
FB Total
RTM
Slot 1
9.0 CFM
8.8 CFM
8.5 CFM
8.9 CFM
35.2 CFM
6.8 CFM
Slot 2
8.8 CFM
8.7 CFM
7.9 CFM
9.6 CFM
35.1 CFM
7.5 CFM
