System Overview
Centellis 2000 Shelf - DC Installation and Use (6806800G45F) 46
 Front and rear ESD wrist strap attachment points
 Rear grounding studs
The system is designed to pass Network Equipment Building Systems (NEBS) level 3
requirements.
1.1.1 Shelf
The 3U (132 mm) high and 420 mm deep shelf for 19" ANSI racks is made of stainless steel.
There is one mounting bracket at each side of the shelf designed for front-mounting the shelf
into a rack.
You can install the system in a standard 19'' ANSI rack.
Figure 1-1 System Front View
Figure 1-2 System Rear View
