Network Management and System Access
Centellis 2000 Shelf - DC Installation and Use (6806800G45F) 136
Virtual Active IP Address on Backplane Interfaces
Virtual Standby IP Address on Backplane Interfaces
Changing the Shelf Manger Virtual IP Address for the Backplane Interface
To change this IP address, you need to modify the first three octets of the Shelf IP Connectivity
Record #1.
1. Change the first two octets of the IP address using the hpiship tool located on
the shelf manager. Use the option -h for help.
2. Reboot the system for the changes to take effect.
Example:
Print current IP address settings and change out-of-band address:
*Print current IP address settings
shm9s8:~ # hpiship
29 {ADVANCEDTCA_CHASSIS,9} Shelf Resource
4097 Shelf Manager IP Address 0
IP : 192.168.9.171
Gateway: 192.168.9.0
Netmask of IP2 Virtual Active IP Address Default Value
255.0.0.0 ...171 172.16.0.171
255.255.0.0 ...171
255.255.255.0 ...171
Netmask of IP2 Virtual Standby IP Address Default Value
255.0.0.0 ...181 172.16.0.181
255.255.0.0 ...181
255.255.255.0 ...181
