Chapter 5
Centellis 2000 Shelf - DC Installation and Use (6806800G45F) 113
Non-Field-Replaceable Units
5.1 Overview
Within the Centellis 2000 Shelf - DC, there are fixed internal components:
 Backplane
 Alarm panel
 Power Inlet
These components are passive and are non-field-replaceable units.
5.2 Backplane
The backplane is fully compliant with the PICMG 3.0 R3.0 Specification and it has been designed
with the following features:
 Two node slots
 Fabric interface channel 1 with direct connection between the two node slots.
The fabric interface channel 2 of node slot 1 is connected to user slot1.
The fabric interface channel 2 of slot 2 is connected to user slot 2.
 Base interface with dual star interconnect
 Update interface between the node slots
 Base interface to the shelf manager slots
 Bused IPMB-0 connections
 Synchronization clock buses
The following interfaces are located within the zone 2:
 Base interface
 Fabric interface
 Update channel interface
 Synchronization clock interface
