Network Management and System Access
Centellis 2000 Shelf - DC Installation and Use (6806800G45F) 129
8.3.2.1 Setting the Shelf Geographical Address
Set the shelf geographical address during the system installation via a network connection.
Setting the Shelf Geographical Address
To set the shelf geographical address, proceed as follows:
1. Log in to the active shelf manager.
2. Change the shelf geographical address:
# hpishaddr -b ""
Where must be two hexadecimal
digits with no leading "0x".
Example: Changing the shelf geographical address to 7:
# hpishaddr -b "07"
3. Reboot the shelf (switch the power off and on again).
The ATCA-MF105 boards will come up with changed IP addresses.
8.3.2.2 Shelf Manager Replacement Scenarios
This subsection describes different scenarios of replacing the shelf manager and determining
the shelf FRU information.
Replacement during normal operation
If a MF105 is replaced during normal operation, the shelf FRU information on the replaced
MF105 is updated upon insertion. The shelf FRU information remains valid.
Replacement during shelf power-off with a spare MF105
The change of shelf address, shelf IP address and FRU activation order takes effect after a
reboot of the system.
