CURRENT_STRENGTH_NEW
Sets the drive strength of a pin. Specify a number (in mA), MIN, or MAX for output or bidirectional pins
that support programmable drive strength. Please refer to the family data sheet for which drive strengths
are allowed for each I/O standard. This option is ignored if it is applied to anything other than an output
or bidirectional pin.
Old Name
CURRENT_STRENGTH
Type
String
Device Support
This setting can be used in projects targeting any Altera device family.
Notes
This assignment supports Fitter wildcards.
Syntax
set_instance_assignment -name CURRENT_STRENGTH_NEW -to
Example
set_instance_assignment -name CURRENT_STRENGTH_NEW 12MA -to output_pin
See Also
IO_STANDARD OUTPUT_TERMINATION
466
CURRENT_STRENGTH_NEW
MNL-Q21005
2015.05.04
Altera Corporation
Quartus Settings File Reference Manual
