2–28 Reference Manual Altera Corporation
Nios Development Board Cyclone II Edition May 2007
Board Components
L24 59 JH1 pmc_ad2
L25 58 JH1 pmc_ad3
M19 55 JH1 pmc_ad4
M22 54 JH1 pmc_ad5
M23 53 JH1 pmc_ad6
R24 51 JH2 pmc_ad7
U22 49 JH2 pmc_ad8
U25 49 JH1 pmc_ad9
W21 48 JH2 pmc_ad10
W23 48 JH1 pmc_ad11
W24 47 JH1 pmc_ad12
W25 46 JH2 pmc_ad13
Y21 45 JH2 pmc_ad14
Y23 46 JH1 pmc_ad15
Y24 31 JH2 pmc_ad16
Y25 32 JH1 pmc_ad17
Y26 29 JH2 pmc_ad18
AA23 29 JH1 pmc_ad19
AA24 28 JH2 pmc_ad20
AA25 28 JH1 pmc_ad21
AA26 27 JH1 pmc_ad22
AB23 26 JH2 pmc_ad23
AB24 23 JH2 pmc_ad24
AB25 23 JH1 pmc_ad25
AB26 22 JH2 pmc_ad26
AC23 22 JH1 pmc_ad27
AC25 21 JH1 pmc_ad28
AC26 20 JH2 pmc_ad29
AD24 19 JH2 pmc_ad30
AD25 20 JH1 pmc_ad31
R20 52 JH1 pmc_be_n0
T22 43 JH2 pmc_be_n1
T24 32 JH2 pmc_be_n2
T25 26 JH1 pmc_be_n3
Table 2–15. PMC Connector Pin Table (Continued)
FPGA Pin JH1 & JH2 Pin Connector Board Net Name
