SDI Clocked Audio Output Registers
The following tables list the registers for the SDI Clocked Audio Output IP core.
Table 5-7: SDI Clocked Audio Output Register Map
Name Bytes Offset
Channel 0 Register 00h
Channel 1 Register 01h
FIFO Status Register 02h
FIFO Reset Register 03h
Table 5-8: SDI Clocked Audio Output Registers
Description Access Name Bit
Channel 0 Register
The user-defined channel number of audio channel 0. RW Channel 0 7:0
Channel 1 Register
The user-defined channel number of audio channel 1. RW Channel status RAM select 7:0
FIFO Status Register
This sticky bit reports the overflow of the clocked audio
output FIFO. RO Active channel 7:0
FIFO Reset Register
Reserved for future use. WO Unused 6:0
Resets the clocked audio FIFO. WO FIFO reset 7
Altera Corporation SDI Audio IP Registers
Send Feedback
5-9 SDI Clocked Audio Output Registers
UG-SDI-AUD
2014.06.30
