EXFO FLS-2600B Tunable Laser Source - Manual (Page 126)

Remote Control
118 FLS-2600B
Programming Commands
Programming Commands
SOURce:SWEep:CONTinuous:PROGram
Description This function is used to set the parameters for a continuous
sweep program. During a sweep program, the application
sweeps continuously between the minimum (start) and
maximum (stop) wavelengths.
Syntax SOUR:SWE:CONT:PROG[],[],
[],[],[],[]
Parameters The and parameters represent the start and stop
wavelengths for the sweep. The current spectral measurement
unit applies (nm or THz). The format must be 9999.999 nm or
999.9999 THz.
The parameter is used to set the speed of the sweep.
The format must be 99.999.
The parameter is the number of passes. The format
must be an integer from 1 to 100 or 0 for continuous.
The parameter indicates whether the reverse option is on
or off. The format must be 1|0.
The parameter indicates whether the trigger option is on
or off. The format must be 1|0.
